AP&S International GmbH
For over 20 years, we have been supplying high-performance wet process equipment for the surface treatment of wafers to the world’s leading semiconductor manufacturers. Our modular product range is perfectly tailored to the needs of the semiconductor industry, whether standard wet process equipment or a customized solution is required.
Chemical wet processes are our passion. As a leading supplier for the semiconductor, MEMS and microelectronics industry, we offer wet process equipment for batch and single wafer processes as well as process supporting equipment!
Far-sighted, customer-oriented, innovative and committed to continuous progress – this is AP&S and its wet process equipment. At home in the semiconductor industry worldwide, we help shape the future of semiconductor production!
Products & Services
Efficient wet process solutions for your semiconductor production. Whether you need a standard system or a customized wet process solution: Our modular product range is perfectly tailored to your needs!
AP&S offers the complete range of wet process equipment from single wafer systems to wet benches for batch processes as well as fab logistics equipment.
The AP&S product range includes manual, semi-automatic and fully automatic wet process solutions for the semiconductor, MEMS and microstructuring industries as well as for the R&D sector. Among others, AP&S equipment covers the following wet processes: cleaning, etching, metal etching, PR stripping, electroless metal deposition, lift-off process, drying, developing and others.
We offer wet process equipment for batch processes as well as for single wafer processing and equipment for ensuring cleanliness and maximum productivity in semiconductor production such as FOUP, SMIF and box cleaners as well as various chemical management systems. AP&S equipment is used in front-end-of-line (FEOL) and back-end-of-line (BEOL) processes.
Osai A.S. S.p.A.
OSAI Automation System S.p.A. Benefit Company, founded in 1991, is a company that designs and manufactures standard equipment for semiconductor testing as well as complete automation lines, with high technology content and through a cross technology portfolio: from test handlers for MEMS (wide range of stimuli units entirely designed by OSAI) up to test and assembly lines for power devices (discrete and modules).
In addition to OSAI headquarters located in Parella, its resale and assistance network is made up of over 40 distributors all over the world, with over 50 local staff and 3 commercial branches (USA, Germany and China).
SUSS
SUSS is a leading supplier of equipment and process solutions for microstructuring in the semiconductor industry and related markets. In close cooperation with research institutes and industry partners SUSS contributes to the advancement of next-generation technologies such as 3D Integration and nanoimprint lithography as well as key processes for MEMS and LED manufacturing. With a global infrastructure for applications and service SUSS supports more than 8,000 installed systems worldwide. SUSS is headquartered in Garching near Munich, Germany. For more information, please visit suss.com.
Products & Services
The SUSS portfolio covers a comprehensive range of products and solutions for backend lithography, wafer bonding and photomask processing, complemented by micro-optical components. After sales, the company supports the entire life cycle of the tools: its range of services begins with the installation and startup of the systems including user training. Once systems are integrated in the customer’s environment, SUSS provides consistent support. Since long life cycles are very common for the company’s equipment, preventive maintenance programs are available, as well as reliable spare parts systems, warranty extensions and system upgrades. SUSS maintains service locations and local support teams in all areas of the globe to provide quick help.
